Description
Propulsion system for Agricultural Drones
Load capacity(liquid) for Agriculture Quadcopter Drone: 40L
Load capacity(liquid) for Agriculture Hexacopter Drone: 60L
Take-off weight for Quadcopter: 80~88kg
Take-off weight for Hexacopter: 120~132kg
Tube size: 50mm
Setup: A12XL-185 (Motor) + 185 FOC 150A (ESC)+
MF4918P (Prop)
Wire material, wire gauge, color: Power wires: 12#AWG red & black
Signal wires: 5P Teflon
Recommended battery: 14~185 (LiPo)
Wire length: 1700÷5mm
Rated thrust: 20~22kg
Weight: 2800g 2% (incl. Wires+prop)
Efficiency at rated thrust: 9.1g/W (20kg)
IP: IPX6
Max. thrust: 43.5kg
Recommended ambient temperature: -30°C ~ 50°C
